MFS 30

The new MFS25/30C has inherited the streamlined cowling of MFS40/50A and with its 25/30 hp it belongs to the coming tohatsu-design-generation. Tohatsu always strives the development and the presentation of a user-friendly engine. New features like the variable idle speed control, the front-mounted shift lever and the cleaning water system ensure a smooth and stable ride and a quick and easy maintenance. The newly optimized gear ratio (26:12 / 2.17) provides more pover torque, which leads to the fastest top speed that can be achieved with four-stroke eninges in the 25/30hp class. This performance also leads to further fuel savings and wider scope than other brands.

(Picture with additional multifunctional tiller)

Tohatsu 4-stroke benefits:

  • Designed with proven technology
  • Advanced cross-flow induction for smooth operation
  • Canister style oil filter for easy replacement
  • Larger capacity oil reservoir for optimum lubrication
  • Tuned intake system for crisp takeoffs
  • Ultra low emission, EPA and CARB approved

High performance and easy operation:

  • Electronic fuel injection
  • The boating industry' first battery-free, manual start EFI 4-stroke
  • Digital CD ignition system for quicker starts
  • Large alternator and rectifier for superior battery charging
  • Adjustable steering friction and trim tab for reducing steering effort
  • Front mounted shift lever for easier operation
  • 6-Position for Trim adjustable, for Shallow Water Cruising possibility
  • Power trim & tilt (EPTS/L Model)
  • Remote Control (EPS/L + EPTS/L Model

Fundamentals for user convenience and reliability:

  • Through-the-prop exhaust for a quiet ride
  • Thermostatically controlled cooling system for consistent engine temperature
  • Stainless steel water pump housing for outstanding durability
  • High grade marine aluminum alloy that provides the ultimate protection against corrosion
  • Zinc coating on internal water passages for superior corrosion resistance
  • Plastic 25 liter fuel tank for 30 and 25; 12 liter fuel tank for 18 and 15, both include fuel fittings and fuel line
  • Aluminum propeller

Warnings and protection:

  • Overheat warning (audible)
  • Safety lanyard (an essential protection feature standard on all Tohatsu outboards)
  • Start-in-gear protection for safer engine starting
  • Over-rev. limiter

Specifications

Cylinders3
Power30.00 HP / 22.06 KW
Capacity526
Bore and stroke61 x 60
Max. Speed range5250-6250
Starter systemmanual or electric
Control systenRemote Control or handle
Gear ratio2.17:1
Propeller Selection area8" - 14"
Water level15", 20"
Fuelunleaded gasoline
Recommended OilFour Stroke Engine Oil
Fuel tank25l separate tank
Weight72.00 kg
Alternator power12V, 180W, 15A
TOSC compatibility*S
All TOHATSU Four Strokes meet EU emission standards
Standard- & Optional Equipment
Type S / L EPS / L EPTS / L
Electric Starter -
Manual Recoil Starter
Decompression Release
Engine Stop Switch Lanyard
Alternator
Rectifier o
Gas Assist Tilt - - -
Power Tilt - -
Transom 15 / 20 15 / 20 15 / 20
Propeller Selection area
Analog Tachometer o o o
Analog Trim Meter - - o
Remote Control Box -
25L Plastic Fuel Tank
Tool Kit
Emergency Starter Rope
Spare Spark Plugs
Owners Manual
Standard       Optional o
  • 3 Cylinder

  • Alternator

  • Batteryless Fuel Injection

  • Charging System

  • Diagnostics

  • Front Shift Control

  • High Solid Paint Coating

  • Low Fuel Consumption

  • Manual Start Back-Up

  • Multi Function Tiller Handle

  • Over Heat Buzzer

  • Power Trim

  • Simple Steering Friction Lever

  • Thermostat

  • Throttle Friction

  • Trolling Speed Control (MFS25/30)

  • Dual Water Intake


download specification file

Dimensions

MFS 30 Dimensions
